Home>Electricity>Alternator>Alternator BMW X1 (F48)
BMW X1 (F48)
Model
Engine
Displacement and power
From To
X1 (F48) sDrive 16 d
B37C15A
CCM:
1496
HP:
116
KW:
85
11.2014 => 05.2022
X1 (F48) sDrive 18 d
B47C20A
CCM:
1995
HP:
150
KW:
110
07.2015 => 06.2022
X1 (F48) sDrive 18 d
B47C20B
CCM:
1995
HP:
150
KW:
110
07.2015 => 06.2022
X1 (F48) sDrive 18 i
B38A15A
CCM:
1499
HP:
140
KW:
103
07.2017 => 06.2022
X1 (F48) sDrive 20 d
B47C20A
CCM:
1995
HP:
163
KW:
120
11.2015 => 05.2022
X1 (F48) sDrive 20 d
B47C20B
CCM:
1995
HP:
163
KW:
120
11.2015 => 05.2022
X1 (F48) sDrive 20 i
B42S20A
CCM:
1998
HP:
192
KW:
141
07.2015 => 06.2022
X1 (F48) sDrive 20 i
B48A20A
CCM:
1998
HP:
178
KW:
131
11.2020 => 06.2022
X1 (F48) sDrive 20 i
B48A20F
CCM:
1998
HP:
178
KW:
131
11.2020 => 06.2022
X1 (F48) xDrive 18 d
B47C20A
CCM:
1995
HP:
150
KW:
110
11.2014 => 06.2022
X1 (F48) xDrive 18 d
B47C20B
CCM:
1995
HP:
150
KW:
110
11.2014 => 06.2022
X1 (F48) xDrive 20 d
B47C20A
CCM:
1995
HP:
163
KW:
120
07.2015 => 06.2022
X1 (F48) xDrive 20 d
B47C20B
CCM:
1995
HP:
163
KW:
120
07.2015 => 06.2022
X1 (F48) xDrive 20 i
B48A20A
CCM:
1998
HP:
178
KW:
131
11.2020 => 06.2022
X1 (F48) xDrive 20 i
B48A20B
CCM:
1998
HP:
192
KW:
141
07.2015 => 06.2022
X1 (F48) xDrive 20 i
B48A20F
CCM:
1998
HP:
178
KW:
131
11.2020 => 06.2022
X1 (F48) xDrive 25 d
B47C20B
CCM:
1995
HP:
231
KW:
170
11.2014 => 05.2022
X1 (F48) xDrive 25 i
B42S20A
CCM:
1998
HP:
231
KW:
170
07.2015 => 10.2021
X1 (F48) xDrive 25 i
B46A20B
CCM:
1998
HP:
231
KW:
170
07.2015 => 10.2021
X1 (F48) xDrive 25 i
B48A20B
CCM:
1998
HP:
231
KW:
170
07.2015 => 10.2021
  • Genuine part : no
  • Type of part : Alternator
  • Motorization : X1 (F48)
  • Can be mounted on : BMW
  • Amperage : 180
  • Number of grooves (pulley) : 6
  • Voltage : 12
  • From : 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022
  • L.1 [ mm ] : 186.00
  • Taille A [ mm ] : 58.00
  • Taille B [ mm ] : 30.00
  • D.3 [ mm ] : M10x1.5
  • Taille C [ mm ] : 76.00
  • COM ID : 34
  • Plug type : PL_2818
  • Pulley : AP
  • D.1 [ mm ] : 10.50
  • D.2 [ mm ] : 10.50
  • O.D.1 [ mm ] : 49.00
  • Type : X1 (F48) sDrive 16 d, X1 (F48) sDrive 18 d, X1 (F48) sDrive 18 i, X1 (F48) sDrive 20 d, X1 (F48) sDrive 20 i, X1 (F48) xDrive 18 d, X1 (F48) xDrive 20 d, X1 (F48) xDrive 20 i, X1 (F48) xDrive 25 d, X1 (F48) xDrive 25 i
  • Engine code : B37C15A, B38A15A, B42S20A, B46A20B, B47C20A, B47C20B, B48A20A, B48A20B, B48A20F
